  • Discription Feature Wireless connection,super low power, remote positive wakeup, quick start
    Usage  Make video talk with guests, record short video, owners can know who comes without opening door.
    Wake-up way Doorbell button, PIR motion detection and mobile call
    Alarm message Quick send within 1 second
    Operating system  Online users Multi-user online watching simultaneously
    Dynamic domain name Inclusive
    Processor A powerful and high-performance programmable Hi3518E processor, built-in ARM926 @Max. 440MHz and high-speed video coprocessor
    Collection Image sensor  1/2.7'' 1080p line-scan CMOS sensor
    Sensor performance Support automatic white balance, automatic gain control, and automatic backlight supplyment
    SNR ≥39dB
    Lens/visual angle 2.6mm @F2.0/166°
    Night vision  IR-CUT auto switch, 6 pcs 850nmΦ28Mil high-power IR lamps, night vision in 10 meters
    IR control IR on  when in night vision mode, IR and ICR automatic detection . IR shuts when night vision stops, and ICR is fixed on day viewing mode.
    Video Compressed format H.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline
    Video coding 1080P/15fps+720P/15fps+VGA/30fps+QVGA/30fps+1080P@1fsJPEG snap
    Resolution 1920*1080
    Audio Input Built-in one-way 38dB Microphone
    Output  Built-in speaker (8Ω1Ｗ)
    Intercom Two-way voice intercom, with echo cancel
    Compression stnadard/code rate ADPCM/32kbps
    Network Network protocol TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP，P2P, etd.
    WIFI 802.11b/g/n
    Network security WPS security encryption
    Wireless connection Smart  WIFI configuration
    Record Recode mode  Motion detection record, doorbell button trigger record, and manual record
    Storage  TF storage card (Max.32G)/ Support cloud storage
    Others Power supply 2pcs 18650 batteries (internationally common)
    Power  Standby current:120μA, working current:170MA
    Work environment Temperature:-10～50℃, Humidity: <95%
    Installation way Door wall mounting
    Material ABS plastic
    Product size 161mmx74mmx36mm
    Product weight about 290G (excluding battery)/set
    Carton size /
