  • Processor RTS3903N
    Sensor SC2235
    Video compression standard H.264
    Audio compression standard G.711a/PCM/AAC
    Audio compression rate G711a 8K-16bit Mono
    Maximum image size 1080P 1920*1080
    Lens field of view 110 degree
    Frame rate 50Hz: 15fps@1080p（2M）
    Storage funtion Suppor Micro SD card(maximum128G)
    Wireless standard 2.4 GHz～2.4835 GHz IEEE802.11b/g/n
    Channel bandwidth Suppor 20/40MHz
    Working temperature and humidity -10℃ - 40℃,humidity is less than 95%(no condensation)
    Power 5V/2.5A
    Power Port USB connection
    Power consumption 10W
    infrared 5-10 meter
    Color temperature 6500-7000
    Color rendering number Ra79-81
    Luminous flux 2500-2700LM
    Beam angle 120 degree
    Lighting distance Radius 5 meter
